| Unit No. | Shaft Dia. | Dimensions (in.) (mm) |
Bolt Used |
Bearing No. |
Housing No. |
Weight (kg) |
||||||||||||
| d | ||||||||||||||||||
| (in.) | (mm) | a | e | i | g | l | s | b | Z | Bi | n | m | (mm) | (in.) | ||||
| MUCFL201 | ¡@ | 12 | 47/16 113 |
335/64 90 |
19/32 15 |
7/16 11 |
1 25.5 |
15/32 12 |
23/8 60 |
15/16 33.3 |
1.2205 31.0 |
0.5000 12.7 |
0.7205 18.3 |
10 | 3/8 | MUC201 | MFL204 | 0.48 |
| MUCFL201-8 | 1/2 | ¡@ | MUC201-8 | |||||||||||||||
| MUCFL202 | ¡@ | 15 | MUC202 | |||||||||||||||
| MUCFL202-10 | 5/8 | ¡@ | MUC202-10 | |||||||||||||||
| MUCFL203 | ¡@ | 17 | MUC203 | |||||||||||||||
| MUCFL204-12 | 3/4 | ¡@ | MUC204-12 | |||||||||||||||
| MUCFL204 | ¡@ | 20 | MUC204 | |||||||||||||||
| MUCFL205 | ¡@ | 25 | 51/8 130 |
357/64 99 |
5/8 16 |
1/2 13 |
11/16 27 |
5/8 16 |
211/16 68 |
113/32 35.8 |
1.3425 34.1 |
0.5630 14.3 |
0.7795 19.8 |
14 | 1/2 | MUC205 | MFL205 | 0.64 |
| MUCFL205-16 | 1 | ¡@ | MUC205-16 | |||||||||||||||
| MUCFL206-18 | 11/8 | ¡@ | 513/16 148 |
439/64 117 |
45/64 18 |
1/2 13 |
17/32 31 |
5/8 16 |
35/32 80 |
119/32 40.2 |
1.5000 38.1 |
0.6260 15.9 |
0.8740 22.2 |
14 | 1/2 | MUC206-18 | MFL206 | 0.93 |
| MUCFL206 | ¡@ | 30 | MUC206 | |||||||||||||||
| MUCFL207-20 | 11/4 | ¡@ | 611/32 161 |
51/8 130 |
3/4 19 |
9/16 14 |
111/32 34 |
5/8 16 |
317/32 90 |
13/4 44.4 |
1.6890 42.9 |
0.6890 17.5 |
1.0000 25.4 |
14 | 1/2 | MUC207-20 | MFL207 | 1.2 |
| MUCFL207 | ¡@ | 35 | MUC207 | |||||||||||||||
| MUCFL208-24 | 11/2 | ¡@ | 67/8 175 |
543/64 144 |
53/64 21 |
9/16 14 |
113/32 36 |
5/8 16 |
315/16 100 |
21/32 51.2 |
1.9370 49.2 |
0.7480 19.0 |
1.1890 30.2 |
14 | 1/2 | MUC208-24 | MFL208 | 1.6 |
| MUCFL208 | ¡@ | 40 | MUC208 | |||||||||||||||
| MUCFL209-28 | 13/4 | ¡@ | 713/32 188 |
553/64 148 |
55/64 22 |
19/32 15 |
11/2 38 |
3/4 19 |
41/4 108 |
21/16 52.2 |
1.9370 49.2 |
0.7480 19.0 |
1.1890 30.2 |
16 | 5/8 | MUC209-28 | MFL209 | 1.9 |
| MUCFL209 | ¡@ | 45 | MUC209 | |||||||||||||||
| MUCFL210-30 | 17/8 | ¡@ | 73/4 197 |
63/16 157 |
55/64 22 |
19/32 15 |
19/16 40 |
3/4 19 |
417/32 115 |
25/32 54.6 |
2.0315 51.6 |
0.7480 19.0 |
1.2835 32.6 |
16 | 5/8 | MUC210-30 | MFL210 | 2.2 |
| MUCFL210 | ¡@ | 50 | MUC210 | |||||||||||||||
| MUCFL211-32 | 2 | ¡@ | 813/16 224 |
71/4 184 |
63/64 25 |
23/32 18 |
111/16 43 |
3/4 19 |
51/8 130 |
25/16 58.4 |
2.1890 55.6 |
0.8740 22.2 |
1.3150 33.4 |
16 | 5/8 | MUC211-32 | MFL211 | 3.3 |
| MUCFL211 | ¡@ | 55 | MUC211 | |||||||||||||||
| MUCFL212-36 | 21/4 | ¡@ | 927/32 250 |
761/64 202 |
19/64 29 |
23/32 18 |
17/8 48 |
29/32 23 |
51/2 140 |
223/32 68.7 |
2.5630 65.1 |
1.0000 25.4 |
1.5630 39.7 |
20 | 3/4 | MUC212-36 | MFL212 | 4.2 |
| MUCFL212 | ¡@ | 60 | MUC212 | |||||||||||||||
